型 号 |
容量 (kVA) |
高压电压 （kV） |
高压电流 （mA) |
低压输入 |
变比 (高/仪) |
温升℃ (30分钟) |
阻抗电压%≤ |
空载电流%≤ |
质量Kg |
|
|
电压(V) |
电流(A) |
|||||||||
|
YDQ-1.5/50 |
1.5 |
50 |
30 |
200 |
7.5 |
500 |
10 |
10 |
5 |
26 |
|
YDQ-3/30 |
3 |
30 |
100 |
200 |
15 |
300 |
10 |
8 |
6 |
32 |
|
YDQ-3/50 |
3 |
50 |
60 |
200 |
15 |
500 |
10 |
6 |
6 |
38 |
|
YDQ-5/50 |
5 |
50 |
100 |
200 |
25 |
500 |
10 |
6 |
6 |
55 |
|
YDQ-10/50 |
10 |
50 |
200 |
200 |
50 |
500 |
10 |
6 |
6 |
85 |
|
YDQ-20/50 |
20 |
50 |
400 |
400 |
50 |
500 |
10 |
6 |
6 |
110 |
|
YDQ-30/50 |
30 |
50 |
600 |
400 |
75 |
500 |
10 |
5 |
5 |
120 |
|
YDQ-50/50 |
50 |
50 |
1000 |
400 |
125 |
500 |
10 |
5 |
5 |
135 |
|
YDQ-5/100 |
5 |
100 |
50 |
200 |
25 |
1000 |
10 |
8 |
6 |
65 |
|
YDQ-10/100 |
10 |
100 |
100 |
200 |
50 |
1000 |
10 |
6 |
6 |
90 |
|
YDQ-20/100 |
20 |
100 |
200 |
400 |
50 |
1000 |
10 |
6 |
6 |
110 |
|
YDQ-30/100 |
30 |
100 |
300 |
400 |
75 |
1000 |
10 |
6 |
5 |
150 |
|
YDQ-50/100 |
50 |
100 |
500 |
400 |
125 |
1000 |
10 |
5 |
5 |
160 |
|
YDQ-20/150 |
20 |
150 |
133 |
400 |
50 |
1500 |
10 |
8 |
6 |
130 |
|
YDQ-30/150 |
30 |
150 |
200 |
400 |
75 |
1500 |
10 |
8 |
6 |
150 |
|
YDQ-50/150 |
50 |
150 |
333 |
400 |
125 |
1500 |
10 |
7 |
6 |
160 |
|
YDQ-100/150 |
100 |
15 |
6667 |
400 |
250 |
150 |
10 |
6 |
6 |
165 |
|
YDQ- 50/200 |
50 |
200 |
250 |
400 |
125 |
2000 |
10 |
8 |
8 |
185 |
|
YDQ-100/200 |
100 |
200 |
500 |
400 |
250 |
2000 |
10 |
8 |
8 |
300 |
|
YDQ-150/200 |
150 |
200 |
750 |
400 |
375 |
2000 |
10 |
8 |
8 |
350 |
|
YDQ-200/200 |
200 |
200 |
1000 |
400 |
500 |
2000 |
10 |
8 |
8 |
500 |
|
YDQ-300/200 |
300 |
200 |
1500 |
400 |
750 |
2000 |
10 |
8 |
8 |
600 |
|
YDQ-50/300 |
50 |
300 |
167 |
400 |
125 |
3000 |
10 |
10 |
8 |
600 |
|
YDQ-100/300 |
100 |
300 |
333 |
400 |
250 |
3000 |
10 |
10 |
8 |
700 |
|
YDQ-150/300 |
150 |
300 |
500 |
400 |
375 |
3000 |
10 |
8 |
8 |
800 |
|
YDQ-200/300 |
200 |
300 |
667 |
400 |
500 |
3000 |
10 |
8 |
8 |
900 |
|
YDQ- 300/300 |
300 |
300 |
1000 |
400 |
750 |
3000 |
10 |
8 |
8 |
1200 |
